29th April 2014 – I updated the code below and I think that now it really is as good as this can possibly get.
Perfect result!
I love both Isotope and Twitter Bootstrap framework, I think they’re great tools for developers & web designers alike.
However, due to the nature of TB’s fluid structure (with widths in % rather than px) and Isotope being originally developed way before this kind of layout structures were popular…. they don’t work nicely together out of the box.
Desandro (who, ironically, is a designer at Twitter), Isotope‘s developer, has recently released a beta for Isotope v.2 and the direction is definitely going towards making the library more accomodating of responsive and fluid layouts.
That said, I still had some trouble to make a full width website work as I wished, while implementing both, but I finally managed to make everything work beautifully.

Also, I am using Infinite Scroll (developed by Paul Irish), imagesLoaded (also developed by Desandro) and WP Imager (developed by me), to accomplish 3 more objectives:
– resize and cache images inside items
– make an endless list of items without needing to click on pagination
– make sure all images inside the items load before firing Isotope (mostly to avoid overlapping of partially formed items, while images are still loading).
All of this, on a WordPress site.
[mt]
So here I’ll show you how they all work together.
Download and setup in your site, the (latest versions of) necessary scripts:
Isotope v2 beta .
Twitter Bootstrap (or use their CDN)
Infinite Scroll
imagesLoaded
WP Imager (keep in mind that this only works on WordPress)
I have removed pretty much all WordPress related code, so feel free to adapt it to whatever you need it for.
Template file
<div id="iso"> <div class="row"> <div class="post col-xs-12 col-sm-6 col-md-3 col-lg-3"> <div class="post_img"><img src="#"></div> <div class="content"> <h2><a href="#">Item Title</a></h2> </div> </div> </div> <div class="pagination"> <a href="#/page/2/">Next</a> </div> </div>
CSS
#iso {
margin: 0 auto;
width: 100%;
}
/* Browser Support of ':first-of-type' pseudo-class
Chrome Safari Firefox Opera IE Android iOS
Works 3.2+ Works 9.5+ 9+ Works Works
*/
#iso .row:first-of-type {
margin: 0;
}
.post {
margin: 10px 0;
max-width: 100%;
padding: 0;
}
.post .content {
padding: 20px;
}
/*
* PAGINATION
*/
.pagination {
display: none;
visibility: hidden;
}
/*
* MEDIA QUERIES
*/
@media (min-width: 768px) and (max-width: 980px) {
#iso .col-md-3, #iso .col-lg-3 {
width: 300px;
}
}
@media (min-width: 980px) and (max-width: 1300px) {
#iso .col-md-3, #iso .col-lg-3 {
width: 350px;
}
}
@media (min-width: 1300px) {
#iso .col-md-3, #iso .col-lg-3 {
width: 400px;
}
}
JS
<script>
$(document).ready(function() {
var $container = $('#iso');
// Fire Isotope only when images are loaded
$container.imagesLoaded(function(){
$container.isotope({
itemSelector : '.post',
masonry: {
isFitWidth: true,
gutter: 20
}
});
});
// Infinite Scroll
$('#iso').infinitescroll({
navSelector : 'div.pagination',
nextSelector : 'div.pagination a:first',
itemSelector : '.post',
bufferPx : 200,
loading: {
finishedMsg: 'We\'re done here.',
//img: +templateUrl+'ajax-loader.gif'
}
},
// Infinite Scroll Callback
function( newElements ) {
var $newElems = jQuery( newElements ).hide();
$newElems.imagesLoaded(function(){
$newElems.fadeIn();
$container.isotope( 'appended', $newElems );
});
});
});
</script>
<!--[if lte IE 8]>
<script>
$(document).ready(function() {
// IE8 compatibility of pseudo-class
$('#iso .row').first().css({margin:'0'});
});
</script>
<![endif]-->
[mt]
There’s probably more solutions on how to achieve all of this, however after I researched extensively, this was the only solution that did the trick for me.
So, take all of this and adapt it to your needs!
Please help… I have a problem with the combination of isotope, infinite-scroll and bootstrap ( newest versions of all at time of posting ) … The new images just won’t render unless I remove the ‘img-fluid’ bootstrap class. Basically the height : auto style causes the loaded images to fail. Please help.
Having overlapping issues? Use $(window).load instead of $(document).ready. To the OP: thanks so much for the post. Lines 31 to 33 made my day!
Labeling this as “Isotope + Twitter Bootstrap + Infinite Scroll + Fluid/Responsive layout” is a bit misleading. All you did was apply the infinitescroll on the container. You don’t even mention how and where you get the data from. And there’s definitely nothing about wordpress in the article. At least include a json example or even better, a php script that loads more data from a database.
The scope of the article wasn’t getting into the WordPress part, but rather the css & js behind having Isotope work with Twitter Bootstrap, which can be problematic for many.
Infinite scroll is just an extra, and again, not the scope of the article. If you want to contribute with a JSON example, you’re more than welcome, I dont have the time, sorry.
The data can be simple html or a basic WP query loop (check the example at the top of the post).
Hi thanks for this write up,
any chance that you could provide a WordPress specific example? I’m trying to do something similar but I’m having trouble trying to get the code to work from WordPress.
Thanks!
How about using JSON data to append new elements?
Check here https://isotope.metafizzy.co/methods.html#appended
elements => Type: Element, jQuery Object, NodeList, or Array of Elements
Thanks @Jany, did that already. I was hoping for a working sample since I can’t make it mine work. For some reason, after ( successfully ) appending new elements to the container, isotope seems NOT to position them. Please see here: https://dl.dropboxusercontent.com/u/102498471/isotope_issue.png how the new elements looks like in the console after appending them.
Any hints?
I haven’t tried but from the sound of it, I would go for a solution like
$container.isotope( 'on', 'appended', function() { $container.isotope('reloadItems'); })In v.1 this was done through reLayout, but I’m guessing this has a similar effect.
You could als try, instead of using appending, the prepended method.
Let me know!
Same result. I tried to put it online on codepen ( https://codepen.io/xyboox/pen/preLq ) but for some reason it’s worse then on my machine :) where at least I have the initial layout worked by isotope, my issue would be only when appending new elements via JSON.
OK, I put my code here: https://dl.dropboxusercontent.com/u/102498471/isotope.zip
Am I doing something wrong?
Thanks!
Ciprian, I tested your code and it works fine on my machine, using FF. I have received emails from people that had the same issue as you, for some reason in some cases there’s an overlapping issue but we can’t seem to be able to reproduce the issue / to understand exactly what’s the cause.
Can you please try to use a solid CSS reset? I wonder if SO/Browser defaults could be the problem.
